Product Summary
Case: JEDEC DO-214AC molded plastic body over
passivated chip
Terminals: Solder plated, solderable per MIL-STD-750,
Method 2026
Polarity: For uni-directional types the color band denotes
the cathode, which is postitive with respect to the anode
under normal TVS operation
Mounting Position: Any
Weight: 0.002 ounces, 0.064 gram
Features
? Optimized for LAN protection applications
? Ideal for ESD protection of data lines in accordance
with IEC 1000-4-2 (IEC801-2)
? Ideal for EFT protection of data lines in accordance with
IEC1000-4-4 (IEC801-4)
? Plastic package has Underwriters Laboratory
Flammability Classification 94V-0
? Glass passivated junction
? Excellent clamping capability
? Low incremental surge resistance
? Fast response time: typically less than 1.0ps from 0 Volts
to V(BR) min.
? 300W peak pulse power capability with a 10/1000μs
waveform, repetition rate (duty cycle): 0.01%
? High temperature soldering guaranteed:
250°C/10 seconds at terminals
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SMAJ100A/11 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
Negotiable |
|
||||||||||||||
|
SMAJ100A/13 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
Negotiable |
|
||||||||||||||
|
SMAJ100A/2F |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
Negotiable |
|
||||||||||||||
|
SMAJ100A/5A |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
Negotiable |
|
||||||||||||||
|
SMAJ100A/63 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
Negotiable |
|
||||||||||||||
|
SMAJ100A-7P |
Micro Commercial Components (MCC) |
TVS Diodes - Transient Voltage Suppressors 100V 400 Watts |
Data Sheet |
|
|
||||||||||||||
|
SMAJ100A-E3/61 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
|
|
||||||||||||||
|
SMAJ100AHE3/61 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 400W 100V 5% Uni |
Data Sheet |
|
|
||||||||||||||
