6N137

TOSHIBA photocoupler, 8-lead DIP, UL1577

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~0.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~0.15

PartNumber:: 6N137

Brand:: Fairchild Semiconductor - Fairchild | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Antonia Leung's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-15

From Other Seller

Part Number:6N137
US $0.01 - 0.15
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 6N137 is TOSHIBA photocoupler. The device consists of a high emitting diode and a one chip photo IC. This unit is 8-lead DIP package. The applications of the 6N137 are digital logic isolation, tele-communication and analog data equipment control. The operating temperature range of the device is 0°C to 70°C.

Parametrics

Absolute maximum ratings: (1) Forward current:20mA; (2) Pulse forward current:40mA; (3) Reverse voltage:5V; (4) output current:50mA; (5) output voltage:7V; (6) supply voltage (1 minute maximum):7V; (7) enable input voltage (not to exceed VCC by more than 500mV):5.5V; (8) output collector power dissipation:85mW; (9) operating temperature range:0°C to 70°C; (10) storage temperature range:-55°C to 125°C; (11) lead solder temperature (10s):260°C.

Features

Features: (1) LSTTL/TTL compatible:5V supply; (2) ultra high speed:10MBd; (3) guaranteed performance over temperature:0°C to 70°C; (4) high isolation voltage:2500Vrms min.; (5) UL recognized:UL1577, File No.E67349.
