LM358

dual low power, operation amplifier, Quad Operational Amplifiers

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~0.50

PartNumber:: LM358

Brand:: STMicroelectronics - ST | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Antonia Leung's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-09

From Other Seller

Part Number:LM358
US $0.01 - 0.50
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM358 is dual differential input operational amplifiers. These amplifiers have several distinct advantages over standard operational amplifier types in single supply applications. They can operate at supply voltages as low as 3.0 V or as high as 32 V, with quiescent currents about one–fifth of those associated with the MC1741 (on a per amplifier basis). The common mode input range includes the negative supply, thereby eliminating the necessity for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.

Parametrics

Absolute maximum ratings:(1)Power Supply Voltages Single Supply, VCC: 32V; (2)Power Supply Voltages Split Supplies, VCC, VEE: ±16V; (3)Input Differential Voltage Range, VIDR: ±32V; (4)Input Common Mode Voltage Range, VICR: –0.3 to 32; (5)Output Short Circuit Duration, tSC: Continuous; (6)Junction Temperature, TJ: 150 °C; (7)Storage Temperature Range, Tstg: –55 to +125 °C; (8)Operating Ambient Temperature Range of LM358: 0 to +70℃.

Features

Features: (1)low power drain; (2)a common mode input voltage range extending to ground/VEE; (3)single supply or split supply operation; (4)pinouts compatible with the popular MC1558 dual operational amplifier; (5)The LM158 series is equivalent to one–half of an LM124.
